COMPENDIUM INCLINATION MEASUREMENT
WYLER AG, WINTERTHUR / SWITZERLAND

8.2 INCLINATION MEASURING INSTRUMENT CLINOTRONIC S

Clinotronic S is building on the success of the Clinotronic PLUS. It keeps those features of the Clinotronic
PLUS, which made it famous, like its reliability, accuracy, and easiness to use - and ads latest technology
to it:
• Wireless functionality
• Excellent display
• User friendly
• Adjusted to local gravity

WIRELESS FUNCTIONALITY
Clinotronic S can be connected to an Android™ or
iOS™ device, which can then be used as remote dis-
plays. This new feature makes the instrument much
more versatile and opens up new applications.

MEASURING PRINCIPLE OF DIGITAL MEASURING SYSTEMS
The measuring principle is based on a differential capacitance measurement of a pendulum providing
excellent repetition, hysteresis as well as start-up behaviour. Combined with a complex evaluation algorithm,
this forms the base of a high-quality handheld tool. The latest version of the reliable inclination measuring
instrument comes with a number of new interesting advantages. The most important of them are:
• Aluminium housing, hard anodised, with heavier walls for more stability. Fulfils the strict CE requirements
(immune to electromagnetic smog)
• Powered by standard 1.5V batteries, allowing cost-
efficient reliability all over the world
• Various connecting possibilities to a PC, also via
wireless data transmission
• All the well known functions remain the same such
as e.g.:
• Easy zero-point adjustment
• Wide variety of different units displayed
Die dazugehörige Software
• Absolute and relative measurement wylerCHART
• As options magnetic inserts and threaded holes are
available
