COMPENDIUM INCLINATION MEASUREMENT
WYLER AG, WINTERTHUR / SWITZERLAND

8.3 INCLINATION MEASURING INSTRUMENT CLINO 2000

The CLINO 2000 is a precision handheld inclination measuring
instrument fulfilling the highest standards.
The CLINO 2000 is designed as a standalone unit, but it can also
be used together with a second instrument for measurements where
a reference is required. Furthermore, it can be connected to a PC /
laptop via a built-in RS 232 interface.
The measured primary values are compared to a stored reference
curve in the CLINO 2000. This allows a very accurate calculation of
the inclination.
This top-level inclinometer with large measuring range brings a great
many advantages to the metrologist.

The most important of them are:
• A highest possible precision over the large measuring range of
±45° / ±60° / ±30° / ±10°, with integrated temperature compensation
• Effortless zero adjustment by using the integrated software and a reversal measurement
• Easy calibration due to implemented software guidance and the calibration aids as part of the
delivery (for the CLINO 2000 / ±45° only)
• Large digital display with the advantage to set all commonly used measuring units
• Built-in possibility to connect an additional instrument for differential measurement or
ZEROTRONIC sensors by using the serial port
• Rugged housing, rust-protected, with prismatic bases
• Built-in cross vial for easy alignment of the secondary vertical setting direction in order to
eliminate “twist error“
• State-of-the-art digital technology
• The instrument is fully compatible with the entire range of WYLER AG digital sensors
• Powered by standard 1.5V batteries, rechargeable batteries or with mains adapter
• Fulfils the strict CE requirements (immunity against electromagnetic smog).
• As an option, magnetic inserts are available

The following measuring units may be selected:

GON /
mm/m xxxx.xx mm/ xxx.xx mm/ Degrees/Arcmin/ xx.xxx
(2 Dec) mm/m relative basis REL Arcsec xx° xx‘ xx‘‘ Grad gon
(3 Dec)
Inch / 10 xx.xxxx‘‘/10“ Zoll/ xx.xxxx ‘‘/ REL Arcmin / Arcsec xxx‘ xx‘‘ per mille xxx.xx%o
Inches relative basis
Inch / 12 xx.xxxx‘‘/12“ Degrees/ xxx° xx‘ Degrees (3 Dec) xx.xxx° artillery per xxx.xx
Inches Arcmin mille
Milliradian xxxx.xx
(2 Dec) mRad
