COMPENDIUM INCLINATION MEASUREMENT
WYLER AG, WINTERTHUR / SWITZERLAND

The following parameters (among others) can be set and changed at the BlueMETER SIGMA:
• Units
• Filter settings
• Relative base length
• Physical address of the Zerotronic sensors
It is possible to send the measured data via an RS232 port to a PC/laptop to the WYLER software
wylerINSERT, wylerCHART, wylerDYNAM and wylerSPEC.
Additional functions and features of the BlueMETER SIGMA:
• New design with aluminum housing and latest technology
• Radio communication based on Bluetooth® technology: a single worldwide standard
• Display of measuring values in various measuring units
(see following list)
• Absolute measurements
• Relative measurements
• Evaluation and storage of the zero-offset of instruments/sensors
• Battery voltage indicator
• Powered by standard 1.5 V batteries size C
• CE compatible

TECHNICAL SPECIFICATIONS BLUEMETER SIGMA
Batteries, size C /
optional rechargeable 1,5 V
External power supply +24 V DC
RS232, asynchronous, 7 DataBits, 2 StopBits, no parity, 9600
Digital output
bps
Length 150 mm
Dimensions Width 96 mm
Height 34/40 mm
Net weight
• with batteries 835 g
• without batteries 684 g

Page 139
