COMPENDIUM INCLINATION MEASUREMENT
WYLER AG, WINTERTHUR / SWITZERLAND

The key features of these new series of instruments are:
• Compact and pleasant design which is functionally optimized
for precision measurement
• Wireless data transmission based on the internationally ap-
proved Bluetooth™ standard (Option)
• Large and easy-to-read LCD display which can be read from
both sides since the handle can be rotated
• Each instrument has its own specific address allowing the
use of several independent systems in the same room wit-
hout interfering with each other BlueSYSTEM, consisting of
• Since each instrument has a built in infrared-receiver, the BlueLEVEL, BlueMETER SIGMA
measurement can be initiated at any instrument and IR-Zapper
• There are three sensitivities available:
• BlueLEVEL 1 μm/m: Range ±20 mm/m
• BlueLEVEL 5 μm/m: Range ±100 mm/m
• BlueLEVEL 10 μm/m: Range ±200 mm/m
• Linearity according to DIN 2276
• All instruments are equipped with RS 232 / RS 485 interfaces
• Powered by standard 1.5V batteries type “C”
• In compliance with CE regulations and all applicable EMC
regulations
The main features of the BlueSYSTEM BASIC instrument are the
same as for BlueSYSTEM, but with the following differences:
BlueSYSTEM BASIC, consisting of
BlueLEVEL BASIC,
• No individual LCD display BlueMETER BASIC and
• There are three sensitivities available: IR remote
• BlueLEVEL 1 μm/m: range ±10 mm/m
• BlueLEVEL 5 μm/m: range ±50 mm/m
• BlueLEVEL 10 μm/m: range ±100 mm/m

Typical configuration of an engineer set for BlueSYSTEM or BlueSYSTEM BASIC:
• 1 BlueLEVEL or BlueSYSTEM BASIC, horizontal version
BlueLEVEL or BlueSYSTEM BASIC with horizontal base, flat contact surfaces of hardened steel,
precision lapped, with dust grooves, base length 150 mm, sensitivity 1 μm/m
• 1 BlueLEVEL or BlueSYSTEM BASIC, angular version
BlueLEVEL or BlueSYSTEM BASIC with angular base, made of cast iron, contact surfaces hand
scraped, horizontal and vertical bases prismatic, base length 150 mm, sensitivity 1 μm/m (can be
used to measure vertical and horizontal planes and shafts)
• 1 BlueMETER/BlueMETER SIGMA or BlueMETER BASIC
• 2 cables, length 2.5 m each

Page 52
