COMPENDIUM INCLINATION MEASUREMENT
WYLER AG, WINTERTHUR / SWITZERLAND

The image at the top right shows an engineer set
with wireless data transmission from the measuring
instruments to BlueMETER. The BlueMETER is also
an interface between the measuring instruments
and the PC/laptop.
The lower picture shows an engineer set con-
nected by cables to the PC/laptop. Set with BlueLEVEL and BlueMETER SIGMA with
wireless data transmission
In each set, which is equipped with radio, the
measurement data can be transmitted via the sup-
plied cables. This can be advantageous if the user
is in an environment where the use of wireless sys-
tems is impossible or prohibited.

Notes on measuring with wireless data Set with BlueLEVEL and BlueMETER SIGMA
transmission: connected by cables
Why is a BlueMETER as an interface to PC/laptop needed, although Bluetooth is available on any PC or
laptop?
Justification for the use of an interface:
• There are different classes of Bluetooth systems, which directly affect the transmission
distance. The Bluetooth components used in WYLER instruments guarantee a transfer of up to
100 meters
• With Bluetooth modules from a PC/laptop, only one device can be controlled. We need a
module with multi-point capabilities
• Setting up the Bluetooth software on a PC/laptop is very complex
• The BlueMETER can be used as a pure display unit without the use of a measuring software.
That is of great advantage if the measurement site is not properly accessible
6.2.2.2 THE BLUESYSTEM BASIC / BLUELEVEL BASIC WITH
BLUEMETER BASIC

The BlueSYSTEM BASIC forms part of the BlueSYSTEM family, the latest generation of electronic incli-
nation measuring instruments and systems. The main difference between the BlueLEVEL BASIC and the
BlueLEVEL are as follows:
Whereas the BlueLEVEL has an individual display in each of the ins-
truments and can therefore be used as a standalone instrument, the
BlueLEVEL BASIC requires a BlueMETER BASIC to display the measuring
values. Furthermore, the measuring range of a BlueLEVEL is double the ran-
ge of a BlueLEVEL BASIC.
The instruments of the BlueSYSTEM BASIC family can be equipped with
wireless data transmission as well.
BlueSYSTEM BASIC
ENGINEERS SET
in combination
with a Laptop

Set with BlueLEVEL BASIC and
BlueMETER BASIC with
wireless data transmission
